Diamond MC101 Commercial Mobile Antenna with Cutting Chart VHF MC - 101

[Comments(0)|Leave your Comment]

Brand:Diamond

Item#:12060823443885

Score:18 (Score change Discount Voucher)

Weight:0 kg.

List Price:~~$10.00~~

Price:$6.00

You Save:$4.00

Qty:

Prev:Diamond MC101 Commercial Mobile Antenna with Cutting Chart VHF MC - 101

Next:Diamond MC101 Commercial Mobile Antenna with Cutting Chart VHF MC - 101

detail

Comment

Payment

Shipping

Diamond MC101 Commercial Mobile Antenna with Cutting Chart VHF MC - 101

136-174MHz VHF Mobile Radio Antenna

Electrical specifications
Frequency Range(MHz)	136-174MHz
Impedance(ohm)	50
Gain (dBi)	3.4
Polarization	Vertical
Radiation	Omni
VSWR	<1.5
Maximum input power (W)	200

Mechanical specifications
Connector	PL259
Height	1420mm
Radome Material	Whip steel
Magnetic base mount	Black
Weight	0.18Kg
Operating temperature (℃)	-40～80

Basic Info.

Model NO.

MC101

Type

Car Antennas

Product Description

Diamond VHF/UHF antenna MC101
We provide better performance&
Reliability products at an affordable price!
Welcome order!
Place of Origin: Taiwan Brand Name: Miamond
Model Number: MC101
Frequency: 134-174 MHz Gain: 3.4dB Max Power: 200W
V. S. W. R: LESS 1.5 Impedance: 50Ω Connector: MP type
Length: 142cm Weight: 180g Type: 5/8 wave (with cutting chart)

Packaging & Delivery
Packaging Detail: Inner plastic bag and outer cardboard cases package
Delivery Detail: 3 days

Specifications
Diamond VHF/UHF antenna MC101
We provide better performance&
Reliability products at an affordable price!
Welcome order!

M-150GSA M-285S MC-101 MC-200 CP-22E F22 F23 BC-100 BC-200 HC-100 HC-200
Model
Frequency
Gain
Max. Power rating
Length
Weight
Conn
Ector
Type

V/UHF mobile whip antenna
M150GS 134 ~ 174 MHz 2.15 dBi 200 W 0.60 m 160 g MP 1/4-wave mobile whip
M285S 144 ~ 174 MHz 3.4 dB 200 W 1.33 m 180 g MP 5/8-wave mobile whip
MC-101 134 ~ 174 MHz 3.4 dB 200 W 1.42 m 180 g MP 5/8-wave mobile whip
MC-200 430 ~ 490 MHz 5.5 dB 200 W 1.02 m 290 g NP 2X5/8-wave mobile whip

V/UHF fixed station antenna
CP-22E 144 ~ 174 MHz 6.5 dB 200 W 2.7 m 1.1 kg MP Omnidirectional 2X5/8-wave
F22 144 ~ 174 MHz 6.7 dB 200 W 3.2 m 1.3 kg MP Omnidirectional 2X7/8-wave,
FRP outershell
F23 144 ~ 174 MHz 7.8 dB 200 W 4.6 m 1.7 kg MP Omnidirectional 3X5/8-wave,
FRP outershell
BC-100 134 ~ 174 MHz 4.5 dB 200 W 1.7 m 0.9 kg MP Omnidirectional 3X5/8-wave,
FRP outershell
BC-200 430 ~ 490 MHz 6.5 dB 200 W 1.7 m 0.9 kg MP Omnidirectional 3X5/8-wave,
FRP outershell

V/UHF handheld antenna
HC-100 134 ~ 174 MHz 2.15 dBi 10 W 0.19 m 45 g TNC 1/4 l (144/430 MHz)
120/150/300/450/800/900 MHz RX only
HC-100B 134 ~ 174 MHz 2.15 dBi 10 W 0.19 m 45 g BNC 1/4 l (144/430 MHz)
120/150/300/450/800/900 MHz RX only
HC-200 350 ~ 520 MHz 2.15 dBi 10 W 0.19 m 45 g TNC 1/4 l (144/430 MHz)
120/150/300/450/800/900 MHz RX only
HC-200B 350 ~ 520 MHz 2.15 dBi 10 W 0.19 m 45 g BNC 1/4 l (144/430 MHz)
120/150/300/450/800/900 MHz RX only
HC-100S 134 ~ 174 MHz 2.15 dBi 10 W 0.19 m 45 g SMA 1/4 l (144/430 MHz)
120/150/300/450/800/900 MHz RX only
HC-200S 350 ~ 520 MHz 2.15 dBi 10 W 0.19 m 45 g SMA 1/4 l (144/430 MHz)
