RFI TLA4100 - 6dBi Transit/Low Profile Mobile Antenna
- Wideband 700 to 2700 MHz performance
- Low profile, vandal resistant radome
- Ground dependent/independent capable
The TLA4100 Antenna is designed specifically for rail, light rail and bus applications and other similarly demanding transit or stationary applications. With a VSWR less than 2.5:1 covering 698 - 2700 MHz, the TLA4100 operates in all cellular bands globally plus the 2.4 GHz ISM band. This antenna also unofficially operates on 2300MHz @ VSWR approximating 1.35:1.
This antenna can be used in both a ground independent and ground dependent installation - maximum gain is achieved by using up to a 1m^2 metal surface as a ground plane.
Designed to meet the following European Traction Industry Standards:
- NF-F-16-101/102 (materials standard)
- EN50155 (vibration standard)
- EN50124-1 (electrical isolation standard)
- Deutsch Bahn high voltage / current specification
Roof mount multiband "Shark Fin" style antenna designed to operate on all mobile phone and wireless broadband frequencies within the one housing. An alternative for use where height is an issue eg. roofs on large motor homes, outdoor data/weather reporting stations, and many more.
Designed utilising a high impact, UV stabilised low Flame, Smoke and Toxicity (FST) radome, the TLA4100 is IP68 rated to fully protect against the ingress of dust and water. This antenna is suitable for installations even in the most demanding of climates.
Streaming live in-car video at Bathurst with two RFI TLA4100 for 4G mobile broadband.
Electrical Specifications
Frequency Range: 698-960 MHz / 1710-2170 MHz / 2400-2700 MHz / 5700-5800 MHz
Input Impedance: 50 Ω
VSWR: <2.5:1
Vertical Beamwidth: 38° @ 698-960 MHz & 180° @ 1710-2700 MHz
Polarisation: Vertical
Radiation: Omnidirectional, Ground Dependent
Maximum Power: 50 Watts
Mechanical/Environmental Specifications
Construction: NF-F-16-102 compliant injection moulded radome / cast aluminium alloy base
Cable: None
Connector: Integrated N Female
Mount: 4 x M6 screws (not included)
Dimensions: 205 x 100 mm (L x W)
