Long Range Mobile Two Way Radio TM-281A
1.Frequency 136-174MHz
2.Output power:MAX 65W
3.Front Speaker
4.Compact size
On or off the road, Kenwd’s TM-281A is a mobile radio you can always count on. As tough as nails, this MIL-STD-compliant transceiver delivers powerful performance, excellent audio clarity, and a host of advanced features. It offers superb operating ease day or night thanks to the large backlit LCD and illuminated keys. So the next time you take off, take the TM-281A.
Description:
1.Frequency Range:136-174MHz
2.Channel: 200 plus 1
3.Impressive Front Speaker
4.Output Power: MAX 65W
5.Built-in CTCSS/DCS
6.Busy Channel Lockout(BCLO)
7. Selectable wide/narrow channel bandwidth
8. . Channel Scan 9.Emergency call
10.Dimension: 160 x 43 x 126 mm
11.Net Weight:1.13kgs
Technacal Specification:
Model | TM-281A/TM-481A |
Frequency range | 136-174MHz/400-430/440-480MHz |
Mode | F3E(FM) |
Antenna Impedance | 50 ohm |
Operating Temperature | -25°C---+60°C |
Power Voltage | 13.8V DC ±15%(11.7-15.8V) |
Dimension | 160*43*137mm |
Weight | 1.2Kg |
Transmitter |
Power output | High 65W |
Frequency Stability | ±2.5ppm |
Spurious Emissions | better than -60dB |
FM noise | ≤-40dB |
Audio distortion | ≤3% |
Max. Frequency Deviation | ≤±5KHz(wide) ≤±2.5KHz(narrow) |
Microphone Impedance | 600ohm |
Receiver |
Frequency Stability | ±2.5ppm |
Sensitivity | Better than 0.18uV(wide)/0.22uV(narrow) |
Modulated bandwidth | ≥ ±7KHz(wide)/3.5Khz(narrow) |
Adjacent channel selectivity | ≥ 60dB |
Intermodulation Rejection | ≥65dB |
Spurious response rejection | ≥65dB |
Audio output power | 2W or Above |
Audio output Impedence | 8 ohm |
tm-281 Standard Package:
1 x TM481/TM281 Mobile Radio
1 x Speaker Mic.
1 x Power Cable
1 x Installation Bracket
1 x Installation Kits (Screws .etc)
1 x User Manual
