Specifications
General |
Model Number | A8 |
Frequency Range | UHF:400-470MHz |
Power | 5W |
Channel Capacity | 16 |
Battery Capacity | Li-ion 1800mAh |
Working Voltage | DC 3.7V |
Antenna Impendence | 50Ω |
Weight (Include battery) | 100g |
Size(Include antenna) | 90x50x23mm |
Transmitter |
Output Power | 5W |
The Maximum Deviation | ≤5KHz |
Residual Radiation | <60dB |
Current | ≤1000mA |
Audio Response | +7~-12.5dB |
Receiver |
Sensitivity | ≤0.16μV(12dB SINAD) |
Squelch Sensitivity | <0.2μV |
Intermodulation | 50dB |
Audio Power | ≥300mW |
Current | ≤100mA |
Squelch Current | 20mA |
Product Features
1. Auto battery save function
2. Low battery alert
Application
Packages
By air/sea or by express, for small order we suggest you can consider sent by express like DHL, FedEx, UPS etc.
1. UPS, DHL, EMS, HK EMS, FEDEX, HK post, TNT and so on (door to door)
2. For air shipment, please choose your favorite shipping method according to your requirements
3. The shipping cost varies in different location, also depends on specific weight. We will recommend the cheapest and safest way according to your detailed quantities.
4. Shipping period varies depending upon your location. Normally, it will take around 3-7days from China to destination country, but some remote places need more add 1-3 days.
FAQ
Q: Brands your products covered
A: yutong brand and other OEM radios.
Q: What is PTT (Push to Talk)?
A: All two way radios have a Push-To-Talk button. This is the button, usually located on the side of the radio, that is held down to make the radio transmit.
Q: Do battery need charge when you get at the first?
A: Upon delivery,battery is not fully charged. Recharge is needed. For Ni-Cd,the first charging should over night. Ni-Mh and Li-ion can stop charge when the light green.
Q: No Power.
A: (1)Check battery installation and/or replace batteries.
(2)Voltage Capacity quickly go out.
(3)The battery life is over, replace new one.
Q: Couldn’t Communicate with other group members.
A: (1)Verify that the channel frequency and the CTCSS you are using are the same as those of your groups members.
(2) If the channel frequency and the CTCSS are the same, verify your groups members are within the radios coverage.
Good After-Sale Service:
(1) Warranty: One year warranty for machines, 6 month for scharger and other accessories.
(2) Please send back the defective goods which are within the warranty period, we will repair them or send you new one for free.
(3) If it is the sample or only few pcs accessories (the fee is less or around shipping fee) are damaged, please send us some pictures and video about it need to confirm your problem, then we will send you free new goods instead.
FAQ
1.Are you factory?
Yes! We are the factory. We also have the EXP.& IMP. company and shipping agent to handling the EXP. procedures.
2.Do you have updated BSCI number?
Yes,we have BSCI audit Certificate.
3. What is your advantage?
1) Speedy sample submission.
2) Plenty of up-to-date material options for your designs.
3) Our own designing and sampling team will help with much more new styles.
4) Our strict review on each shape will lead to nice looking styles.
5) Our experienced QC team will overlook both pre-production quality and final packed production quality.
4. Can you pass tests? Are you familiar with them?
Yes,we can pass tests.We are familiar with US and EU standards.
5. What's the price term?
Usually our price is FOB South China Ports, such as Xiamen, Guangzhou, or Ningbo.
6.Can I order sample to check your quality?
Yes,we can send the available sample in 3 days. New developing sample will need more time,about 5 to 21 days.
7.Can I add my logo or customize my own design?Can you make design for us?
Yes,we can put your logo or develop your own design if you meet minimum quantity requirement.
We can design artwork for your confirmation before making samples.
8.Do I need to pay for sample?
The sample charge is subject to the product. Please send us inquiries for more details.
9.What's your MOQ?
Please don't worry about minimum quantity, because we will try to find solution for you even you order small quantity. Please discuss with our sales.
10.How can I make the payment?
Online Trade Assurance Payment is welcome. We also accept L/C, T/T, Western Union and so on.
11.When will you deliver my order after payment?
Our delivery time for sample order is from 24hours to 14days.
Our delivery time for mass production order is from 15 to 60 days.
12.How can I know product cost and shipping cost if I don't submit online order?
We can send spread sheets with product pictures and cost details.We have agreement with express and logistics companies to get cheaper freight rate. Please contact our sales to order spread sheets.
Your satisfaction is our motivation! Please contact Interphone Electronics team Without hesitation!
If bulk order, please contact Mr Andrew:
Tel: 86(595)22392886
Fax: 86(595)22392886
WhatsApp / Viber / LINE / Telegram: 0086 18105059187
WeChat / IMO: 0086 18105059187
SKYPE: baofeng-william
Email: interphone07@gmail.com
