Quick Details
Model Number: NX-320
Type: Handheld
Dimensions: 56 X 110.5X 66.9mm
Frequency Range: 440-470MHz
Storage Channel: 16
Talk Range: 5-10km
Name: NX-320
Warranty: 1 year
Weight: 325g
Price: factory wholesale price
Screen: yes
Battery: long life LI-ION
Color: black
Certification: CE,FCC
Material: PVC+ABS
Advantage
Kenwood digital wireless walkie talkie NX-220/NX-320 with full keypad
Specification:
Frequences | UHF1: 400-470MHz |
Channel Capacity | 16 |
Zone Capacity | 64(each with a maximum of 16 channels) |
Channel Spacing | 12.5KHz/20KHz/25KHz |
Operating Voltage | 7.4V (rated) |
Battery | 2000mAh (Li-Ion) |
Frequency Stability | ±1.5ppm |
Antenna Impedance | 50Ω |
Dimensions (H×W×D) | 56 X 110.5X 66.9mm |
(with standard battery, without antenna) |
Weight (with antenna & standard battery) | 325g |
Transmitter |
RF Power Output | UHF1/UHF2/UHF3 High Power: 4W |
UHF1/UHF2/UHF3 Low Power :1W |
VHF High Power: 5W/VHF Low Power: 1W |
FM Modulation | 11KΦF3E @ 12.5KHz/14KΦF3E @ 20KHz |
16KΦF3E @ 25KHz |
4FSK Digital Modulation | 12.5KHz Data Only: 7K60FXD |
12.5KHz Data & Voice: 7K60FXW |
Conducted/Radiated Emission | -36dBm<1GHz/-30dBm>1GHz |
Modulation Limiting | ±2.5KHz @ 12.5KHz/±4.0KHz @ 20KHz |
±5.0KHz @ 25KHz |
FM Hum & Noise | 40dB @ 12.5KHz/43dB @ 20KHz/45dB @ 25KHz |
Adjacent Channel Power | 60dB @ 12.5KHz/70dB @ 20/25KHz |
Audio Response | +1 ~ -3dB |
Audio Distortion | ≤3% |
Digital Vocoder Type | AMBE++ or SELP |
Digital Protocol | ETSI-TS102 361-1, -2,-3 |
Receiver |
Sensitivity | Analog | 0.3μV (12dB SINAD)/0.22μV (Typical) (12dB SINAD) |
0.4μV (20dB SINAD) |
Digital | 0.3μV /BER5% |
Selectivity |
|
TIA-603 | 60dB @ 12.5KHz/70dB @ 20&25KHz |
ETSI | 60dB @ 12.5KHz/70dB @ 20&25KHz |
Intermodulation |
|
TIA-603 | 70dB @ 12.5/20/25KHz |
ETSI | 65dB @ 12.5/20/25KHz |
Spurious Response Rejection |
|
TIA-603 | 70dB @ 12.5/20/25KHz |
ETSI | 70dB @ 12.5/20/25KHz |
Blocking |
|
TIA-603 | 80dB |
ETSI | 84dB |
Hum and Noise | 40dB @ 12.5KHz/43dB @ 20KHz/45dB @ 25KHz |
Rated Audio Power Output | 0.5W |
Rated Audio Distortion | ≤3% |
Audio Response | +1 ~ -3dB |
Conducted Spurious Emission | < -57dBm |
Application
Packages
By air/sea or by express, for small order we suggest you can consider sent by express like DHL, FedEx, UPS etc.
1. UPS, DHL, EMS, HK EMS, FEDEX, HK post, TNT and so on (door to door)
2. For air shipment, please choose your favorite shipping method according to your requirements
3. The shipping cost varies in different location, also depends on specific weight. We will recommend the cheapest and safest way according to your detailed quantities.
4. Shipping period varies depending upon your location. Normally, it will take around 3-7days from China to destination country, but some remote places need more add 1-3 days.
FAQ
1. What is your radios warranty?
Radio body:1 year, accessories: 6 months
2. What is your lead time for the radio?
2-3 days for order prepare after we get payment. Add 5-6 days for Express transportation.
3. What payment method can your company provide?
T/T ,Western Union
4. Can you offer CO,CE these documents for radio customs clearance?
Yes, we can help you find the agent to do for you, but the CE /COO cost need to be paid by yourself.
5. Can you offer the sample for me to test the quality first?
Yes, we can offer the sample , but sample cost and shipping cost need to pay by yourself, the fee will return to you when place order.
6. What is the MOQ for the radio?
Lower price radio:6pcs.
High price radio:2pcs.
7. Do you have radio agent certificate?
Yes, we are Motorola, Hytera, Baofeng, Vertex these radio authorized agent, all of these certificates we have and can offer to you
8. What kind of payments do you accept?
A: We usually accept T/T. For small amount, we accept Paypal too.
Production Process
Quality is the soul of a product. Yutong believes in strict selection of raw materials. Over 90% of the materials we use to manufacture products are far above the industrial stardard. Moverover, we have a specialized QC department to manage and inspect the quality of both raw materials and finished products. Complying with ISO9001 quality management system and GB/T19001-2008 (AQL) sampling inspection, Yutong follows the complete inspection standards of IQC, IPQC, FQC and OQC. Yutong has a long-standing business relationship with world leading suppliers like Phillips, Fujitsu, Panasonic, Sony and Samsung to ensure FPY (First Pass Yield) in production and stability in use.
